STANDARD USB TYPE-C PLUG CABLE ASSEMBLY

Factory-backed connector sourcing and electric connection support for OEMs, distributors and electronic equipment manufacturers.

Product View
STANDARD USB TYPE-C PLUG CABLE ASSEMBLY

OEM Ready

Factory Supply

Fast Quote

Product Specifications

Key parameters for OEM, distributor and engineering evaluation.

Parameters

Custom Engineering Support

Tailored cable assembly & wire harness designs to meet your exact application requirements.

Full Technical Datasheets

Electrical ratings, mechanical drawings, material specs and compliance certifications on request.

Factory Direct Pricing

Competitive OEM & distributor pricing with flexible MOQ for both prototype and volume orders.

UL / CE Compliance Ready

Products engineered and tested to meet North American and European regulatory standards.

Need detailed parameters for this product?

Submit a quote request below -- our engineering team typically responds within one business day with full specifications, samples availability and lead times.

Detailed Product Information

Technical Data & Reference

Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.

Specifications

Number of Pins
9 Pins
Key Position
Type C
Left Connector
Type-C Plug
Right Connector
USB3.0 Plug
AWG Gauge
22 AWG ~ 30 AWG
Connection Type
Plug and unplug
Wires & Cables Length
Customization length

Material Composition

Material Value / Description
Housing & Insulation PBT
Contacts Copper Alloy, Gold-Plated
Shell Copper Alloy, Nickel & Gold-Plated
Sealing -
Shielding Shield
Overmolding PVC
Wires & Cables Conductor Tinned Copper
Wires & Cables Jacket PVC / TPE

Technical Characteristics

Characteristic Value
Rated Current 5A
Rated Voltage 30V
Rated Temperature -25°C ~ + 85°C
Flame Retardant Grade VW-1 / UL94V-0
Insulation Resistance ≥ 100 MΩ
Contact Resistance ≤10mΩ
Durability ≥ 10000 Times
Protection Grade -
Product Certification ISO 9001:2015
Production Design Standards IPC 620

Application Scenarios

  • Machine Vision Systems: Ensures high-speed, stable data and power transmission between industrial cameras and processing units.

  • Industrial Automation & Robotics: Provides robust connectivity for PLCs, robotic arms, and Autonomous Mobile Robots (AMRs) operating in demanding environments.

  • Medical Equipment: Delivers secure and reliable plug-and-play interfaces for diagnostic devices and patient monitoring systems.

  • Test & Measurement Instruments: Highly durable construction (rated for 10,000 mating cycles) designed for frequent plugging and unplugging in laboratory and field testing equipment.

Frequently Asked Questions

Can the length and wire gauge of this USB Type-C cable assembly be customized?
Yes, we offer full customization for cable length, AWG gauge (ranging from 22 AWG to 30 AWG), and jacket materials (PVC or TPE) to perfectly match your OEM design requirements.
Is this Type-C to USB 3.0 cable suitable for industrial environments?
Absolutely. It features comprehensive shielding, durable PVC overmolding, and an operating temperature range of -25°C to +85°C, making it highly reliable for machine vision and automation setups.
What is the durability rating of these connectors?
The robust copper alloy, gold-plated contacts are engineered for heavy-duty use, supporting a durability rating of over 10,000 mating cycles.
Do you offer flexible MOQs for bulk manufacturing?
Yes, as a factory-direct manufacturer, we provide flexible Minimum Order Quantities (MOQs) to support both your initial prototype testing and long-term volume production.

Overview and Application Notes

Product Overview: Industrial-Grade USB Type-C to USB 3.0 Cable Assembly

Engineered for demanding OEM applications, this 9-Pin USB Type-C to USB 3.0 cable assembly delivers reliable data transmission and robust power delivery (up to 5A/30V). Designed to bridge modern Type-C interfaces with legacy high-speed USB 3.0 systems, it is an essential interconnect solution for industrial automation, vision control systems, and commercial electronics.

Unlike standard consumer cables, our assemblies are built with factory-grade materials, including full shielding against electromagnetic interference (EMI) and a ruggedized PVC/TPE overmolding, ensuring stable performance in harsh environments.

Core Technical Advantages

  • High-Durability Connectivity: Featuring gold-plated copper alloy contacts and a premium PBT housing, the connectors are rated for ≥ 10,000 mating cycles, drastically reducing maintenance costs in high-frequency plug/unplug scenarios.

  • Optimal Signal Integrity: The shielded twisted-pair construction and tinned copper conductors (22 AWG to 30 AWG options) guarantee minimal signal loss, which is critical for real-time data streaming.

  • Safety & Compliance: Manufactured under IPC 620 standards with a VW-1 / UL94V-0 flame retardant grade, ensuring safe operation across a broad temperature range (-25°C to +85°C).

Comprehensive Application Notes

Our custom wire harness and cable solutions are tailored for equipment manufacturers across multiple high-tech sectors:

  • Machine Vision & Industrial Cameras: Provides the high bandwidth required for frame grabbers and industrial cameras, ensuring zero-latency image transmission for automated visual inspection systems.

  • Robotics & Factory Automation: Ideal for routing through robotic arms, AGVs (Automated Guided Vehicles), and PLCs, where vibration resistance and durable wire bending are strictly required.

  • Test & Measurement Equipment: Serves as a reliable data bridge for laboratory instruments, oscilloscopes, and diagnostic tools requiring stable interface connections.

OEM Customization & Manufacturing Support

As a direct factory supplier, EDOM Electronics supports full customization for this cable assembly. Whether you need specific cable lengths, custom AWG configurations, specialized jacket materials (PVC, TPE, or PUR), or integrated panel-mount connectors, our engineering team can provide rapid prototyping and flexible MOQ support for your BOM.
