USB Connectors: Type-C Type-A Micro-B Sourcing for OEM

USB Connectors

Dual-Port Stacked USB 3.0 Type-A Receptacle, Horizontal PCB Mount (PN: EU18FL1N1234)

Drop-in for: GSB311231HR / TE Connectivity 1932258-1 / Molex 48405-0001 Mates With: 3.0 Type-A Male Cable Assemblies / Plugs

Gender: : Dual Receptacle
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : Yes
Mating Cycles: : 1,500
Current Rating: : 1.8A
Number of Contacts: : 18
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

Micro USB 2.0 5-Pin Receptacle, SMT Without Pegs (PN: MUSB05F-78569)

Alt. for: 2.0 SMT Receptacles (e.g., Molex 47346 series or similar) Mates With: 2.0 Type-B Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 1A
Number of Contacts: : 5
Voltage Rating: : 30V AC/DC
USB Connector Style: : Micro
USB Version: : 2.0
Interface: : B
Waterproof: : N/A
Approvals: : IEC
PCB Mount Position: : Edge Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Surface Mount
Mating Face Lead In: : N/A

View Details Datasheet

USB Connectors

Quad-Port Stacked USB Receptacle (2x USB 3.0, 2x USB 2.0), Through-Hole (PN: EU26FB3N12236)

Intermateable With: GSB31 Series / Wurth Elektronik 69020 Series equivalent (4-port stacked configurations) Mates With: 3.0 & 2.0 Type-A Male Cable Assemblies

Gender: : Four-layer Receptacle
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 1,500
Current Rating: : 1.8A
Number of Contacts: : 26
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Through Hole
Mating Face Lead In: : With

View Details Datasheet

USB Connectors

USB 3.0 20-Pin Internal Header Plug, Right Angle THT (PN: EU20MB4M1200)

Drop-in for: 3.0 2x10 Header equivalents) Mates With: 3.0 20-Pin (19-Pin) IDC Cable Receptacles (Front Panel Cables)

Gender: : Plug
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 3,000
Current Rating: : 1.8A
Number of Contacts: : 20
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type E
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.0 Type-A Dual Receptacle, Stacked Right-Angle Through-Hole (PN: EU18FL3N12225)

Intermateable With: GSB311131HR / Molex 48405-0001 Mates With: 3.0 Type-A Male Cable Assemblies

Gender: : Dual Receptacle
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 1,500
Current Rating: : 1.8A
Number of Contacts: : 18
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Through Hole
Mating Face Lead In: : With

View Details Datasheet

USB Connectors

USB 3.0 Type-A Female Receptacle Connector, Right Angle Through-Hole (PN: EU09FL2N12207)

Drop-in for: GSB311131HR / TE Connectivity 1929967-1 / Molex 48405-0003 Mates With: 3.0 Type-A Male Plugs / Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 1,500
Current Rating: : 1.8A
Number of Contacts: : 9
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.0 Type-A Female Receptacle, Mid-Mount, Right Angle (PN: EU09F2L3N12343SR)

Drop-in for: 1932258-1 / Amphenol GSB311131HR (Functional equivalent) Mates With: 3.0 and backward-compatible USB 2.0 Type-A Plugs (Cable Assemblies)

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 1,500
Current Rating: : 1.5A
Number of Contacts: : 9
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Through Hole
Mating Face Lead In: : N/A

View Details Datasheet

USB Connectors

USB 3.0 Type-A Female Receptacle, Right Angle, Mid-Mount (PN: EU09FL3N12247)

Drop-in for: 1932258-1 / Amphenol GSB311131HR Series (Functional equivalent) Mates With: 3.0 and backward-compatible USB 2.0 Type-A Plugs (Cable Assemblies)

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 5,000
Current Rating: : 1.8A
Number of Contacts: : 9
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Through Hole
Mating Face Lead In: : N/A

View Details Datasheet

USB Connectors

USB 3.0 Type-A Female Receptacle, Right Angle, Reverse Mid-Mount (PN: EU09FL1N12155)

Drop-in for: 1932258-1 / Amphenol GSB311131HR (Functional equivalent) Mates With: 3.0 and backward-compatible USB 2.0 Type-A Plugs (Cable Assemblies)

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 1.5A
Number of Contacts: : 9
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet
