Custom Cable Assemblies

0.4mm Pitch 40-Pin Micro-Coaxial Shielded Cable Assembly 40AWG 50 Ohm LVDS/FPGA-RF Harness

Intermateable With: 20878-040T-01 / I-PEX CABLINE-CA II 40-Pin Series Mates With: 20525-040E Series 0.4mm Pitch 40-Pin Board Receptacle Header

Cable Type: : Shielded Micro-Coaxial Cable Assembly (LVDS / FPGA-RF Harness)
Number of Positions / Pins: : 40 Pins
Pitch: : 0.4 mm
Orientation Configuration: : P1: Goldfinger Down / P2: Goldfinger Up (1-to-1 Pinout)
Overall Cable Length: : 60.5 mm (+2.5 / -1.5 mm)
Wire Gauge & Impedance: : 40 AWG, 50 Ohms Micro-Coaxial Cable (41 PCS)
Strain Relief Method: : UV Adhesive Encapsulation at Both Soldering Points
Standard Compliance: : RoHS Compliant, 100% Electrical Tested

View Details Datasheet

HIGH SPEED CABLE

QSFP+ / Mini-SAS HD to Mini-SAS High-Speed Server Cable Assembly

Drop-in for: SFF-8644 (Mini-SAS HD), and SFF-8088 High-Speed Cable Series Compatible Mates With: (SFF-8644) host adapters, and Mini-SAS (SFF-8088) storage expansion enclosures.

Connector A (Host): : 1 x 36-Pin Mini-SAS (SFF-8087)
Data Rate: : Up to 6 Gbps per Channel
Connector B (Target): : 4 x 7-Pin SATA Receptacles
Total Bandwidth: : Up to 24 Gbps
Wire Gauge (AWG): : 30 AWG (Customizable)
Impedance: : 100 Ohms (Differential)
Cable Length: : 0.5m to 1m (Custom Lengths Available)
Configuration: : Forward Breakout (Host to Drive)

View Details Datasheet

HIGH SPEED CABLE

QSFP+ to Mini-SAS (SFF-8088 / SFF-8644) High-Speed Server Cable Assembly

Drop-in for: Amphenol / TE Connectivity QSFP+ to Mini-SAS Cable Series Compatible Mates With: (SFF-8436) and External Mini-SAS (SFF-8088) / Mini-SAS HD (SFF-8644) Receptacles

Number of Pins: : 38-Pin (QSFP+) to 26/36-Pin (Mini-SAS)
Data Rate: : Up to 40 Gbps
Connector A: : QSFP+ (SFF-8436) Plug
Connector B: : Mini-SAS (SFF-8088 / SFF-8644) Plug
Wire Gauge (AWG): : 28 AWG / 30 AWG (Customizable)
Cable Type: : Direct Attach Copper (DAC), Twinax
Cable Length: : Custom Lengths Available
Impedance: : 100 Ohms Differential

View Details Datasheet

HIGH SPEED CABLE

QSFP+ to Mini-SAS HD (SFF-8644) / Mini-SAS (SFF-8088) High-Speed DAC Cable Assembly

Drop-in for: Amphenol / TE Connectivity QSFP+ to Mini-SAS Cable Series Compatible Mates With: (SFF-8436) Switch Ports and External Mini-SAS HD (SFF-8644) / Mini-SAS (SFF-8088) Storage Receptacles

Connector A: : QSFP+ (SFF-8436) Plug
Data Rate: : 40 Gbps (QSFP+) / Up to 12Gbps per SAS lane
Connector B: : Mini-SAS HD (SFF-8644) or SFF-8088
Impedance: : 100 Ohms Differential
Cable Type: : Direct Attach Copper (DAC), Twinax
Wire Gauge (AWG): : 28 AWG / 30 AWG (Customizable)
Cable Length: : 0.5m to 5m (Custom Lengths Available)
Assembly Standard: : IPC/WHMA-A-620

View Details Datasheet

HIGH SPEED CABLE

QSFP+ to Mini-SAS HD (SFF-8644) High-Speed DAC Server Cable Assembly

Drop-in for: Amphenol / TE Connectivity QSFP+ to Mini-SAS HD Cable Series Compatible Mates With: (SFF-8436) Switch Ports and External Mini-SAS HD (SFF-8644) Storage Receptacles.

Connector A (Host): : QSFP+ (SFF-8436) Plug
Connector B (Target): : Mini-SAS HD (SFF-8644) Plug
Data Rate: : Up to 40 Gbps (12Gbps per SAS lane)
Impedance: : 100 Ohms (Differential)
Cable Type: : Direct Attach Copper (DAC), Twinax
Wire Gauge (AWG): : 28 AWG / 30 AWG (Customizable)
Cable Length: : 0.5m to 5m (Custom Lengths Available)
Assembly Standard: : IPC/WHMA-A-620
