USB Connectors: Type-C Type-A Micro-B Sourcing for OEM

USB Connectors

USB 3.1 Type E Front Panel Internal Header, Key A, 20-Pin (PN: EU20F2B3N11350SR)

Drop-in for: G881H2022CEU / Lotes ABA-USB-054-K01 Mates With: 3.1 Type E Front Panel Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 1,500
Current Rating: : 1.5A
Number of Contacts: : 2x10
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type E
USB Version: : 3.1
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : With

View Details Datasheet

USB Connectors

USB 3.1 Type-C 16-Pin Receptacle, Top Mount L6.5mm, Hybrid SMT/DIP (PN: EU16F2B3N11377SR)

Drop-in for: 105450 / TE Connectivity 2320115 series Mates With: Standard USB Type-C Plugs / USB Type-C Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 16
Voltage Rating: : 5V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Through Hole
Mating Face Lead In: : N/A

View Details Datasheet

USB Connectors

USB 3.1 Type-C 24-Pin Receptacle, Mid-Mount R/A Hybrid SMT/DIP (PN: EU24FB3M1137)

Drop-in for: 3.1 Type-C 24-Pin Mid-Mount SMT+DIP Receptacle Mates With: Standard USB Type-C Plugs and Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 1.5A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : 240W
Contact Pin Type: : Hybrid
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.1 Type-C 24-Pin Receptacle, Top Mount Hybrid SMT/DIP 90° (PN: EU24FB3N61312)

Drop-in for: 3.1 Type-C 24-Pin Top Mount SMT+DIP Receptacle Mates With: Standard USB Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Hybrid
Shell Stake Type: : Through Hole
Mating Face Lead In: : N/A

View Details Datasheet

USB Connectors

USB 3.1 Type-C Receptacle, Mid-Mount 1.0mm Dual SMT, Short Body (L=8.75mm) (PN: EU24FB3N11305)

Drop-in for: 105444 Series / TE Connectivity 2320115 Series (Depending on exact PCB cutout tolerances) Mates With: 3.1 Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 3A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Surface Mount
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.1 Type-C Receptacle, Mid-Mount CH0.75mm Hybrid SMT+DIP L9.21mm (PN: EU24F2B3N11339SR)

Drop-in for: 105444 Series / TE Connectivity 2320115 Series (Depending on specific PCB cutout tolerances) Mates With: 3.2 Gen2 Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Hybrid
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.1 Type-C Receptacle, Top Mount Dual SMT R/A (PN: EU24FB3N11253)

Drop-in for: 105450-0101 / TE Connectivity 2320115-1 (Standard Top Mount 24-Pin Receptacles) Mates With: Standard USB Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 5V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.2 Gen2 Type-C Receptacle, Mid-Mount 1.60mm, Dual SMT (PN: EU24F2B3N11406SR)

Drop-in for: 105444 Series / TE Connectivity 2320115 Series (Depending on exact PCB cutout tolerances) Mates With: Standard USB Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 1.5A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : N/A

View Details Datasheet
