Detailed Product Information
Technical Data & Reference
Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.
Competitor & Cross-Reference
- Alternative Type
- Drop-in Replacement
- Competitor Part Number
- Phoenix Contact / Metz Connect / TE Connectivity M12 X-Code Series (e.g., Phoenix SAC-8P-M12MSX/ RJ45)
- Mates With
- Standard M12 X-Code 8-pin panel mount receptacles (e.g., IEC 61076-2-109 compliant sockets)
Drop-in Replacement: This part is a direct, pin-compatible substitute for the competitor part number listed above. No design modification required.
Technical Specifications
- Number of Pins
- 8 Pins
- Key Position
- X-Code
- Left Connector
- M12 X-Code Plug (Male)
- Right Connector
- RJ45 Plug (Shielded)
- AWG Gauge
- 24 AWG ~ 26 AWG
- Connection Type
- Screw Locking (M12)
- Data Protocol
- Cat6a (Up to 10 Gbps)
- Cable Length
- Fully Customizable
- IP Rating
- IP67 (M12 Mated Condition)
- Standard
- IEC 61076-2-109
Material Composition
| Material | Value / Description |
|---|---|
| Housing & Insulation | PA (Polyamide), UL94 V-0 |
| Contacts | Copper Alloy, Gold-Plated |
| Shell | Copper Alloy, Nickel-Plated |
| Sealing | NBR / FKM O-Ring |
| Shielding | Tinned Copper Braid & Foil (360°) |
| Overmolding | Blue or Green TPU |
| Wire Conductor | Stranded Tinned Copper |
| Cable Jacket | TPU |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Current Rating | 1A |
| Voltage Rating | 30V |
| Contact Resistance | ≤ 5 mΩ |
| Insulation Resistance | ≥ 10 MΩ (DC300V) |
| Operating Temp. | -20°C to +80°C |
| Mating Cycles | ≥ 500 Cycles |
| Conductor Resistance | ≤ 5 Ω |
Application Scenarios
-
Machine Vision & Inspection Systems: Delivers secure, high-bandwidth 10Gbps data transfer for GigE Vision industrial cameras requiring flawless image capture without dropped frames.
-
Industrial Automation & PROFINET: Provides robust, vibration-proof network connections between programmable logic controllers (PLCs), network switches, and distributed I/O in harsh factory environments.
-
Robotics & Motion Control: When equipped with a durable TPU jacket, it offers excellent oil resistance and continuous flex life for drag chains and robotic arm communications.
-
Railway & Transportation: Ensures dependable, EMI-shielded data links for passenger information systems and onboard diagnostic networks subjected to constant mechanical shock.
-
Outdoor Sensor Hubs: Offers reliable IP67 ingress protection against moisture, dust, and coolants, keeping critical diagnostic networks online in demanding washdown environments.
Frequently Asked Questions
Does this M12 X-Code cable support 10 Gigabit Ethernet?
Yes, our M12 X-Code assemblies are manufactured to Cat6a specifications and fully support 10GBASE-T data transmission speeds up to 10 Gbps, making them ideal for high-speed industrial networks.
Can I customize the cable jacket material and length for a specific application?
Absolutely. As an OEM manufacturer, we offer customized lengths and can supply robust Blue or Green TPU materials, which provide excellent durability, flexibility, and oil resistance for both static and demanding high-flex industrial applications.
What does the IP67 rating cover?
The IP67 rating applies to the M12 X-Code connector side when correctly mated and locked to a corresponding panel receptacle. It ensures complete protection against dust ingress and temporary immersion in water. The standard RJ45 end is intended for IP20 internal cabinet connections.
Are your cables compliant with international industry standards?
Yes, our M12 X-Code products are designed strictly according to the IEC 61076-2-109 standard and are manufactured in compliance with RoHS, CE, and IPC/WHMA-A-620 quality guidelines.
What is the typical Minimum Order Quantity (MOQ) and lead time?
We offer flexible MOQs to support both your initial prototyping and large-scale mass production. Standard OEM production lead times typically range from 2 to 4 weeks depending on specific material requirements.
Overview and Application Notes
Overview: Engineered for high-speed data transmission in harsh manufacturing environments, our M12 X-Code to RJ45 Waterproof Cable delivers up to 10 Gbps (Cat6a) bandwidth for Industrial Ethernet and PROFINET networks. Built to comply with the IEC 61076-2-109 standard, this rugged cable assembly features a secure M12 screw-locking mechanism on one end and a standard shielded RJ45 plug on the other. With full 360-degree EMI/RFI shielding, gold-plated contacts, and IP67-rated ingress protection (on the M12 side), it guarantees flawless signal integrity amidst severe mechanical vibration and electrical noise. As a factory-direct OEM/ODM manufacturer, we provide tailored solutions including custom cable lengths, specific body shell materials (Blue or Green TPU), and flexible MOQ options to support your equipment builds globally.
Application Notes:
-
Data Speed & Protocol: Fully supports 10GBASE-T, PROFINET, EtherCAT, and GigE Vision protocols. Ensure network switches and target devices are equally rated to prevent system bottlenecks.
-
EMI/RFI Shielding: Continuous 360-degree shield termination through the X-cross inner shield to the metallic outer shell is mandatory to prevent crosstalk and high-frequency interference in heavy motor environments.
-
Torque Specifications: The M12 screw-locking nut must be tightened to the recommended torque (typically 0.4 to 0.6 Nm) to ensure the NBR O-ring provides a long-term IP67/IP68 waterproof seal.
-
Dynamic Routing: For robotic or drag-chain applications, specify our highly flexible PUR jacket option and adhere to a minimum dynamic bend radius of 10x the cable’s outer diameter (OD).
