HDMI Connectors

HDMI Type A 19-Pin Female 180° Straddle Mount Connector (1.20mm PCB)

Drop-in for: 47151-6001, Amphenol 10029449-211RLF Mates With: Standard HDMI Type A Male Cable Plugs

Interface Type: : HDMI Type A Female Receptacle
Pin Count: : 19 Positions
Orientation / Mounting: : 180° Straddle Mount / Edge Mount
Contact Pitch: : 0.50 mm (Pad Pitch 1.00 mm staggered)
Shell Thickness: : 0.50 mm (T = 0.50 mm)
Recommended PCB Thickness: : 1.20 mm
Environmental Compliance: : RoHS Compliant

View Details

HDMI Connectors

HDMI Type A 19-Pin Female Receptacle Short Body SMT Connector with Flange

Drop-in for: 47151-1001, Amphenol 10029449-111RLF, TE Connectivity 2007435-2 Mates With: Standard HDMI Type A Male Cable Plugs

Interface Type: : HDMI Type A Female Receptacle
Pin Count: : 19 Positions
Contact Pitch: : 0.50 mm
Design / Form Factor: : Short Body , SMT Type
Mechanical Features: : With Flange / Mounting Ear (M3.0*0.5), Without Logo, Without Convex
Recommended PCB Thickness: : 1.20 mm to 1.60 mm
Coplanarity: : 0.10 mm Max
Environmental Compliance: : RoHS Compliant

View Details

HDMI Connectors

HDMI Type A 19-Pin Female Receptacle SMT Connector

Drop-in for: 47151-0001, Amphenol 10029449-001RLF, TE Connectivity 2007435-1 Mates With: Standard HDMI Type A Male Cable Plugs

Interface Type: : HDMI Type A Female Receptacle
Pin Count: : 19 Positions
Contact Pitch: : 0.50 mm
Mounting Type: : SMT (Surface Mount Technology) with Through-Hole Shell Tabs
Orientation / Design: : Right Angle, Without Shell Flange / Convex, Without Rear Cover, Without Logo
Recommended PCB Thickness: : 1.20 mm to 1.60 mm
Environmental Compliance: : RoHS Compliant

View Details

HDMI Connectors

HDMI Type A 19-Pin Male Straddle Mount Connector (1.20mm – 1.60mm PCB)

Drop-in for: 47266-0001, Amphenol 10029449-311RLF, TE Connectivity 2013978-1 Mates With: Standard HDMI Type A Female Receptacles / Ports

Interface Type: : HDMI Type A Male Plug (AM)
Pin Count: : 19 Positions
Mounting Type: : Straddle Mount / Edge Mount
Recommended PCB Thickness: : 1.20 mm to 1.60 mm
Environmental Compliance: : RoHS Compliant

View Details

HDMI Connectors

HDMI Type A Female Sinking DIP H3.75 Connector

Mates With: Standard HDMI Type A Male Cable Plugs

Connector Type: : HDMI Type A Receptacle (Female)
Number of Positions / Pins: : 19 Pins
Mounting Type: : Forward Sinking DIP (Through-Hole)
Profile Height (H): : 3.75 mm
Below-Board Height: : 1.80 mm
Body Depth: : 11.65 mm (12.55 mm with shell tabs)
Front Width: : 15.00 mm (18.30 mm leg-to-leg)
Recommended PCB Thickness: : 1.20 mm to 1.60 mm
Mating Durability: : 10,000 Cycles Min.
Compliance: : RoHS Compliant, Lead-Free

View Details

HDMI Connectors

HDMI Type C Female SMT Mid-Mount 1.50mm Beveled Neutral Connector

Intermateable With: 46765-0301 / 46765-1001 (Mini HDMI Type C SMT Series) Mates With: Standard HDMI Type C (Mini HDMI) Male Cable Plugs & Adaptors

Connector Type: : HDMI Type C (Mini HDMI) Receptacle
Number of Positions / Pins: : 19 Pins
Mounting Type: : SMT Mid-Mount (Sinking Mount)
Key Dimensions: : Profile Height: 1.50mm ± 0.12mm; Width: 11.20mm; Depth: 7.50mm
Recommended PCB Thickness: : 1.00mm to 1.20mm
Center-to-Center Pitch: : 0.40mm pin pitch / 0.80mm pin span
Mating Durability: : 10,000 Cycles
Branding / Logo: : Neutral / Without Logo
Standard Compliance: : RoHS Compliant, Lead-Free Reflow Capable

View Details

HDMI Connectors

HDMI Type-A 19-Pin Reverse Mid-Mount Receptacle, Sinking DIP CL0.22 BH2.99mm

Alt. for: 47151-0001, TE Connectivity 2013978-1, Amphenol 10029449-001RLF, Wurth Elektronik 685119136923 Mates With: Standard HDMI Type-A Male Plugs & Cable Assemblies

Gender: : Receptacle (Female)
Number of Positions: : 19 Contacts
Connector Interface: : HDMI Type-A
PCB Orientation: : Horizontal / Reverse (Mid-Mount)
PCB Mount Position: : Sink / Sunken Mount
Board Standoff Height (BH): : 2.99mm
Center Line (CL): : 0.22mm
Termination Style: : Through Hole DIP
Recommended PCB Thickness: : 1.20mm to 1.60mm
Mating Cycles (Durability): : 10,000 Cycles

View Details

HDMI Connectors

HDMI Type-A 19-Pin Reverse Mid-Mount Receptacle, Sinking DIP H2.78mm

Intermateable With: 47151-0001, TE Connectivity 2013978-1, Amphenol 10029449-001RLF, Wurth Elektronik 685119136923 Mates With: Standard HDMI Type-A Male Plugs & Cable Assemblies

Gender: : Receptacle (Female)
Number of Positions: : 19 Contacts
Connector Interface: : HDMI Type-A
PCB Orientation: : Horizontal / Reverse (Mid-Mount)
PCB Mount Position: : Sink / Sunken Mount
Board Standoff / Drop Height: : 2.78mm
Termination Style: : Through Hole DIP / Hybrid
Mating Cycles (Durability): : 10,000 Cycles

View Details

HDMI Connectors

Micro HDMI Type D 19-Pin Female Connector, Top-Mount Dual-Row SMT, Center Height CH=1.55mm | EDOM

Drop-in for: 46765-0301 / Amphenol 10029449 Series Mates With: 19-Pin Male Cable Plug

Connector Type: : Micro HDMI Type D Receptacle (Female)
Number of Positions: : 19 Pin
Mounting Type: : Top-Mount / On-Board, Dual-Row SMT
Center Height (CH): : 1.55 mm
Mating Durability: : 10,000 Cycles
Environmental Compliance: : RoHS Compliant, Lead-Free
Packaging Method: : Tape & Reel (T&R) for Automated SMT Pick-and-Place

View Details
