Competitor & Cross-Reference
- Mates With
- Standard HDMI Type A Male Cable Plugs
Technical Specifications
- Connector Type
- HDMI Type A Receptacle (Female)
- Number of Positions / Pins
- 19 Pins
- Mounting Type
- Forward Sinking DIP (Through-Hole)
- Profile Height (H)
- 2.78 mm
- Front Width
- 15.00 mm (18.00 mm shell tabs)
- Connector Depth
- 12.70 mm
- Recommended PCB Thickness
- 1.20 mm to 1.60 mm
- Mating Durability
- 10,000 Cycles Min.
- Compliance
- RoHS Compliant, Lead-Free
Material Composition
| Material | Value / Description |
|---|---|
| Housing Material | Thermoplastic (UL 94V-0), Color: Black |
| Contact Material | Copper Alloy (T=0.20 mm) |
| Contact Plating | Gold (Au) / Tin Plated |
| Shell Material | Stainless Steel (T=0.50 mm) |
| Shell Plating | Nickel (Ni) Plated |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Contact Resistance | 20 mΩ Max. |
| Insulation Resistance | 1000 MΩ Min. |
| Dielectric Withstanding Voltage | AC 500V, 1 Minute |
| Operating Temperature | -25°C to +85°C |
| General Tolerances | ±0.05 mm (PCB Layout) |
Application Scenarios
-
Ultra-thin Displays, Monitors & Television Motherboards
-
Industrial Single Board Computers (SBC) & Box PCs
-
Digital Signage Media Players & Streaming Devices
-
Audio/Video Switchers, Extenders & Splitters
-
Embedded Control Boxes & In-Vehicle Telematics Units
Frequently Asked Questions
What are the mounting characteristics of the Forward Sinking DIP H2.78 HDMI connector?
It mounts into a cutout on the PCB edge with a profile height of 2.78mm. Four through-hole tabs provide grounding stability across an 18.00mm retention width, allowing slim enclosure designs without compromising mechanical retention.
What is the recommended PCB thickness for this HDMI receptacle?
The recommended printed circuit board thickness is 1.20mm to 1.60mm to ensure proper solder tail penetration and reliable through-hole DIP joint formation.
What electrical standards and environmental tolerances does it meet?
It features a contact resistance of ≤20 mΩ, insulation resistance of ≥1000 MΩ, AC 500V dielectric withstand voltage for 1 minute, and operates between -25°C and +85°C.
Overview and Application Notes
This standard HDMI Type A 19-position female receptacle features a forward sinking DIP configuration with a 2.78mm profile height, engineered for board-edge PCB cutouts in thin audiovisual hardware, commercial displays, and industrial embedded systems.
Key Features
- Form Factor & Pinout: HDMI Type A 19-pin female receptacle with forward sinking DIP mounting.
- Low-Profile Design: Compact 2.78mm profile height with a 12.70mm body depth to reduce overall PCB vertical clearance.
- Robust Shielding: Stainless steel shell (T=0.50mm, Nickel plated) providing strong EMI/RFI suppression and mechanical durability.
- Signal Contact Material: 19 copper alloy contacts with gold/tin plating for reliable high-speed data transmission.
- Durability Rating: Rated for a minimum of 10,000 mating cycles.
- Operating Temperature: Fully rated for operation across -25°C to +85°C.
Engineering Specifications & PCB Integration
Designed for secure edge-mount through-hole soldering, this connector features four retention grounding tabs (pitch spacing 18.00mm, depth spacing 7.57mm to 11.07mm) and 0.50mm pitch signal contacts. This dual-row contact arrangement delivers optimal solder joint reliability, resistance against mechanical insertion stress, and clean ground return paths for high-definition digital multimedia signals.
