Detailed Product Information
Technical Data & Reference
Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.
Competitor & Cross-Reference
- Alternative Type
- Drop-in Replacement
- Competitor Part Number
- Amphenol GSB311231HR / TE Connectivity 1932258-1 / Molex 48405-0001
- Mates With
- Standard USB 3.0 Type-A Male Cable Assemblies / Plugs
Drop-in Replacement: This part is a direct, pin-compatible substitute for the competitor part number listed above. No design modification required.
Material Composition
| Material | Value / Description |
|---|---|
| Contact Material | Phosphor Bronze / Copper Alloy |
| Contact Plating | Selective Gold Plating on Contact Area, Tin on Solder Tails, over Nickel Underplate |
| Housing Material | Thermoplastic (PBT), UL94V-0 Rated, Blue (Pantone 300C) |
| Shield / Shell | Brass or SPCC Steel (Nickel Plated) |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Rated Voltage | 30V AC/DC |
| Current Rating | 1.8A (Power Pins), 0.5A (Signal Pins) |
| Dielectric Withstanding Voltage | 500V AC per minute |
| Insulation Resistance | 1000 MΩ Min. |
| Contact Resistance | 30 mΩ Max. |
| Operating Temperature | -55°C to +105°C |
| Mating Cycles | 1,500 Cycles Min. |
| Flammability Rating | UL94V-0 |
Application Scenarios
-
Industrial PCs & Embedded Automation Controls : Provides high-speed dual USB 3.0 expansion ports on compact motherboard designs for connecting peripheral sensors, flash drives, and vision cameras.
-
Networking Routers & Edge Gateways : Offers high-density I/O connectivity in network hardware where panel space is at a premium and dual SuperSpeed data access is required.
-
Medical Diagnostic Equipment & Workstations : Ensures reliable, EMI-shielded signal transmission for external diagnostic modules and handheld data logging devices.
-
Automotive & Transportation Control Units : Delivers robust through-hole mechanical retention capable of enduring high-vibration environments in commercial vehicle fleet telemetry.
Frequently Asked Questions
Are compliance certifications like RoHS and REACH available for this connector?
Yes. All our connectors, including the EU18FL1N1234 dual USB 3.0 receptacle, strictly comply with RoHS 3.0 and REACH environmental standards. Material test reports and compliance certificates are available upon request.
What customization options are available for OEM orders?
As an OEM manufacturer, we offer custom gold plating thicknesses (from Gold Flash up to 30u"), custom pin tail lengths, alternative shell staking options, and modified housing materials to meet high-temperature or specific environmental requirements.
What is the minimum order quantity (MOQ) and typical production lead time?
Our standard MOQ for connector components is 1,000 pieces. Sample prototyping takes approximately 3–5 days, while full volume production lead time typically ranges from 2 to 3 weeks depending on order quantity.
What mounting style and shell configuration does this dual USB 3.0 connector feature?
The EU18FL1N1234 features a 90-degree right-angle through-hole (DIP) mounting style with a flangeless outer shell (without external spring tabs) and 4 heavy-duty shell solder tabs for PCB thicknesses ranging from 1.20mm to 1.60mm.
Can this connector withstand standard wave soldering automated assembly?
Yes. The insulator housing is molded from durable PBT (Thermoplastic) capable of withstanding standard wave soldering profiles. Please refer to standard PBT thermal guidelines to prevent housing deformation during automated assembly.
Overview and Application Notes
-
Overview: The EU18FL1N1234 is an industrial-grade, dual-port stacked USB 3.0 Type-A female receptacle designed for 90-degree right-angle through-hole (DIP) horizontal PCB mounting. Featuring an 18-pin configuration (9 pins per port) with a flangeless (without lead-in spring fingers/tabs) outer shell design, it delivers SuperSpeed data transfer rates up to 5 Gbps while maximizing PCB front-panel space. Constructed with durable UL94V-0 rated thermoplastic (PBT, Pantone 300C blue) insulators, gold-flash and tin-plated copper alloy contacts, and a nickel-plated brass/SPCC shield, this connector operates across an industrial temperature range of -55°C to +105°C with a tested durability of 1,500 mating cycles. It provides a rugged, space-saving I/O solution for industrial computing, networking gateways, and embedded automation systems.
-
Application Notes:
-
PCB Hole Footprint & Thickness: Ensure the PCB layout strictly matches the 18-pin DIP contact layout (18X dia 0.70mm) and 4-shell grounding tabs (4X dia 2.30mm) per drawing EU18FL1N1234. Recommended PCB thickness is 1.20mm to 1.60mm.
-
Shell Grounding & Retention: Fully solder all four brass/SPCC shell DIP legs to the board ground plane to provide continuous EMI/RFI shielding and absorb insertion/withdrawal forces, protecting internal pin solder joints.
-
Flangeless Enclosure Integration: Featuring a clean, flangeless mating face (without outer shell lead-in springs), ensure panel cutout dimensions allow precise clearance and bezel alignment during system assembly.
-
Wave Soldering Parameters: The UL94V-0 PBT insulator is compatible with standard lead-free wave soldering profiles. Control peak temperature exposure to prevent thermal distortion of the dual-stacked housing.
