Material Composition
| Material | Value / Description |
|---|---|
| Housing | Hi-Temp Plastic LCP, UL 94V-0 Rated |
| Contact | Copper Alloy (T=0.20mm) |
| Shell | Copper Alloy (T=0.20mm) |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Insertion Force | 40N Max. |
| Extraction Force | 2N Min. |
| Durability | 10,000 Cycles |
| Mounting Type | SMT |
| Current Rating | 0.5 Amperes |
| Dielectric Withstanding Voltage | AC 500V R.M.S. |
| Insulation Resistance | 1000 MΩ Minimum |
| Contact Resistance | 40 mΩ Maximum |
| Operating Temperature | -25℃ ~ +85℃ |
Application Scenarios
-
Tablet & Consumer Electronics : Provides a reliable, low-profile memory expansion interface for compact portable devices, ensuring stable data transfer for high-capacity SD cards.
-
Industrial Data Logging Equipment : Offers a robust surface-mount connection with high mating cycle durability (10,000 cycles), ideal for secure data storage and firmware updates in industrial environments.
-
Automotive Infotainment Systems : Delivers secure memory card retention with a built-in card detection switch, ensuring consistent media playback and navigation data access even under vibration.
-
Medical Diagnostic Devices : Ensures consistent and secure read/write contact for portable medical equipment requiring external SD card memory for patient data logging.
Frequently Asked Questions
Is this SD card connector RoHS compliant?
Yes, this product is fully RoHS compliant, meeting environmental safety standards.
What is the mounting type for this connector?
It features a Surface Mount Technology (SMT) design, making it suitable for automated PCB assembly.
Overview and Application Notes
-
Overview : The BSDF11B1N1115 is a high-reliability, surface-mount (SMT) SD card connector engineered for secure memory expansion in compact and demanding electronics. Featuring a built-in normally-open (NO) card detection switch and durable copper alloy contacts (0.5A rated), this connector ensures stable data transmission and robust mechanical retention. Constructed with a high-temperature LCP (UL94V-0) housing and a shielded outer shell, it operates reliably across a temperature range of -25°C to +85°C. With a proven durability of 10,000 mating cycles, it provides an ideal storage I/O solution for tablets, industrial data loggers, and automotive infotainment systems.
-
Application Notes :
-
PCB Footprint & Assembly: The surface-mount (SMT) design requires accurate solder paste application to ensure strict pad coplanarity. Thanks to its Hi-Temp LCP housing, the connector is fully compatible with standard RoHS lead-free reflow soldering profiles.
-
Card Detection System: Integrates a normally-open (NO) switch that closes upon successful card insertion. Engineers should route this CD pin to the system microcontroller to reliably trigger memory mounting and dismounting sequences.
-
Grounding & Retention: Ensure the outer metallic shell mounting pads are fully soldered to the PCB ground plane. This not only minimizes EMI (Electromagnetic Interference) susceptibility but also maximizes mechanical peel strength to withstand repeated card insertions and extractions.
-
