Product Category

Wire Harness Manufacturing

Browse our wire harness and custom cable assembly catalog, featuring servo cables, waterproof cabling, and LAN patch cables with technical pinouts and datasheets.

Looking for end-to-end OEM wire harness manufacturing support, DFM engineering reviews, or custom harness prototyping? Explore our Wire Harness Manufacturing Services.

53 products found

Browse available products in this category.

M8 connector

M8 5-Pin Male Shielded Sensor Cable Assembly, IP67 Waterproof

Drop-in for: M8 Series (e.g., Binder 718/768 Series 5-Pin Male Shielded Plugs). Mates With: M8 5-pin female panel mount receptacles or extension cables (IEC 61076-2-104 compliant).

Number of Pins: : 5 Pins
Key Position: : B-Code / A-Code (Optional)
Left Connector: : M8 Male Plug (Straight / Right Angle)
Right Connector: : Custom (Bare wire, Female socket, etc.)
AWG Gauge: : 24 AWG / 26 AWG
Connection Type: : Threaded Screw Locking (M8x1.0)
IP Rating: : IP67 (Mated Condition)
Cable Length: : Fully Customizable

View Details Datasheet

M8 connector

M8 6-Pin Female Shielded Sensor Cable Assembly, A-Coded, IP67 Waterproof

Intermateable With: M8 6-Pos Shielded Sensor Cables (e.g., Phoenix Contact equivalent shielded models). Mates With: M8 6-Pin A-Coded Male Plugs / Panel Mount Connectors

Number of Pins:: : 6 Pos
Key Position:: : A-Code
Connector Type:: : M8 Socket (Female)
Connection Type:: : Threaded Screw Locking (M8 x 1.0)
Wire Gauge:: : 24 AWG (or 26 AWG Custom)
Cable Length:: : Customization length
Termination:: : Overmolded
Cable End:: : Flying Leads / Blunt Cut / Custom

View Details Datasheet

M8 connector

M8 6-Pin Male Shielded Sensor Cable Assembly, A-Coded, IP67 Waterproof

Intermateable With: M8 6-Pos Shielded Sensor Cables (e.g., Phoenix Contact equivalent shielded models). Mates With: M8 6-Pin A-Coded Female Panel Mount Receptacles / Sockets

Number of Pins:: : 6 Pos
Key Position:: : A-Coded
Connector Type:: : M8 Plug (Male)
Connection Type:: : Screw Locking (M8 x 1.0)
Wire Gauge:: : 22 AWG (or 24 AWG Custom)
Cable Length:: : Customization length
Termination:: : Overmolded
Cable End:: : Flying Leads / Custom

View Details Datasheet

M8 connector

M8 8-Pin Female Shielded Sensor Cable Assembly, A-Coded, IP67 Waterproof

Intermateable With: M8 8-Pos Shielded Sensor Cables (e.g., Phoenix Contact equivalent shielded models). Mates With: M8 8-Pin A-Coded Male Plugs / Panel Mount Connectors

Number of Pins:: : 8 Pos
Key Position:: : A-Code
Connector Type:: : M8 Socket (Female)
Connection Type:: : Threaded Screw Locking (M8 x 1.0)
Wire Gauge:: : 24 AWG (or 26 AWG Custom)
Cable Length:: : Customization length
Termination:: : Overmolded
Cable End:: : Flying Leads / Blunt Cut / Custom

View Details Datasheet

M8 connector

M8 8-Pin Male Shielded Sensor Cable Assembly, A-Coded, IP67 Waterproof

Intermateable With: M8 8-Pos Shielded Sensor Cables (e.g., Phoenix Contact equivalent shielded models). Mates With: M8 8-Pin A-Coded Female Panel Mount Receptacles / Sockets

Number of Pins:: : 8 Pos
Key Position:: : A-Coded
Connector Type:: : M8 Plug (Male)
Connection Type:: : Threaded Screw Locking (M8 x 1.0)
Wire Gauge:: : 24 AWG (or 26 AWG Custom)
Cable Length:: : Customized to requirements
Termination:: : Overmolded
Cable End:: : Flying Leads / Blunt Cut / Custom

View Details Datasheet

UNDERWATER CABLE

Micro Circular MCBH5M 5-Pin Underwater Cable Assembly

Drop-in for: MCBH5M / MCIL5M equivalents (Engineered as a highly reliable, cost-effective factory alternative). Mates With: MCBH5F (Bulkhead Female) or MCIL5F (Inline Female) Micro Circular connectors.

Connector A (Male):: : MCBH5M (Bulkhead/Inline)
Connector B (Female):: : MCBH5F or Flying Leads
Number of Pins:: : 5 Pins
Wire Gauge:: : 22 AWG PTFE
Connection Type:: : Push-Pull (Wet-Mateable)
Cable Length:: : Fully Customizable

View Details Datasheet

UNDERWATER CABLE

Micro Circular MCIL5F / MCIL5M 5-Pin Underwater Cable Assembly

Drop-in for: MCIL5F / MCBH5M equivalents (Engineered as a highly reliable, cost-effective factory OEM alternative). Mates With: MCBH5M (Bulkhead Male) or MCIL5M (Inline Male) Micro Circular connectors.

Connector Type:: : MCIL5F / MCIL5M
Mating Connector:: : MCBH6M / MCIL6M
Number of Contacts:: : 5 Pins
Wire Gauge:: : 20 AWG
Connection Mechanism:: : Push-Pull (Wet-Mateable)
Cable Length:: : Fully Customizable (e.g., 1m - 50m)

View Details Datasheet

UNDERWATER CABLE

Micro Circular MCIL5M to MCIL5F 5-Pin Underwater Cable Assembly

Drop-in for: MCIL5M / MCIL5F equivalents (Engineered as a highly reliable, cost-effective factory OEM alternative). Mates With: MCBH5F (Bulkhead Female), MCBH5M (Bulkhead Male), and equivalent standard 5-pin micro circular mating halves.

Connector Type:: : MCIL5M (Inline Male) to MCIL5F (Inline Female)
Connection Mechanism:: : Push-Pull (Wet-Mateable)
Number of Contacts:: : 5 Pins
Wire Gauge:: : 20 AWG (Standard) / Custom
Cable Length:: : Fully Customizable (e.g., 1m - 50m)
Indexing:: : Integrated Alignment Key

View Details Datasheet

INDUSTRIAL WIRE HARNESS

Micro MATE-N-LOK 3.0mm 14-Pin to 0.110 Faston Multi-Branch Motor Luminaire Wire Harness | EDOM

Alt. for: 1-794617-4 (Housing), TE 1-794610-2 (Gold Contacts), TE 140717-1 (0.110 Faston Receptacles) Mates With: 3.0mm 14-Pin Headers (e.g., 1-794618-4 / 1-794620-4) or standard 0.110" (2.8mm) Male Quick-Disconnect Tabs

Harness Type: : Micro MATE-N-LOK 3.0mm 14-Pin to 0.110 Faston Splitter Harness
Connector P1: : 14-Position Receptacle Housing, 3.0mm Pitch (TE 1-794617-4 equivalent)
Secondary Terminations (P2): : 16x 0.110" (2.8mm) Non-Insulated Quick-Connect Receptacles (TE 140717-1 equivalent)
Wire Gauge & Style: : UL1007 22 AWG Stranded Wire (Red / Blue)
Branch Lengths: : Signal Leads: 500±10 mm to 600±10 mm; Daisy-Chain Links: 150±10 mm
Identification & Marking: : Digital White Heat Shrink Tubing with Printed Wire Markers (KP1–KP8, +12V)
Terminal Pull Force Standard: : UL486A Compliance
Manufacturing Standard: : IPC/WHMA-A-620E Compliance
Packaging Method: : 10 PCS / PE Bag + Label
Environmental Compliance: : RoHS Compliant

View Details Datasheet
