Product Category

Wire Harness Manufacturing

Browse our wire harness and custom cable assembly catalog, featuring servo cables, waterproof cabling, and LAN patch cables with technical pinouts and datasheets.

Looking for end-to-end OEM wire harness manufacturing support, DFM engineering reviews, or custom harness prototyping? Explore our Wire Harness Manufacturing Services.

59 products found

Browse available products in this category.

Micro Circular MCBH5M 5-Pin Underwater Cable Assembly
UNDERWATER CABLE

Micro Circular MCBH5M 5-Pin Underwater Cable Assembly

Drop-in for: MCBH5M / MCIL5M equivalents (Engineered as a highly reliable, cost-effective factory alternative). Mates With: MCBH5F (Bulkhead Female) or MCIL5F (Inline Female) Micro Circular connectors.
Connector A (Male):
: MCBH5M (Bulkhead/Inline)
Connector B (Female):
: MCBH5F or Flying Leads
Number of Pins:
: 5 Pins
Wire Gauge:
: 22 AWG PTFE
Connection Type:
: Push-Pull (Wet-Mateable)
Cable Length:
: Fully Customizable
Micro Circular MCIL5F / MCIL5M 5-Pin Underwater Cable Assembly
UNDERWATER CABLE

Micro Circular MCIL5F / MCIL5M 5-Pin Underwater Cable Assembly

Drop-in for: MCIL5F / MCBH5M equivalents (Engineered as a highly reliable, cost-effective factory OEM alternative). Mates With: MCBH5M (Bulkhead Male) or MCIL5M (Inline Male) Micro Circular connectors.
Connector Type:
: MCIL5F / MCIL5M
Mating Connector:
: MCBH6M / MCIL6M
Number of Contacts:
: 5 Pins
Wire Gauge:
: 20 AWG
Connection Mechanism:
: Push-Pull (Wet-Mateable)
Cable Length:
: Fully Customizable (e.g., 1m - 50m)
Micro Circular MCIL5M to MCIL5F 5-Pin Underwater Cable Assembly
UNDERWATER CABLE

Micro Circular MCIL5M to MCIL5F 5-Pin Underwater Cable Assembly

Drop-in for: MCIL5M / MCIL5F equivalents (Engineered as a highly reliable, cost-effective factory OEM alternative). Mates With: MCBH5F (Bulkhead Female), MCBH5M (Bulkhead Male), and equivalent standard 5-pin micro circular mating halves.
Connector Type:
: MCIL5M (Inline Male) to MCIL5F (Inline Female)
Connection Mechanism:
: Push-Pull (Wet-Mateable)
Number of Contacts:
: 5 Pins
Wire Gauge:
: 20 AWG (Standard) / Custom
Cable Length:
: Fully Customizable (e.g., 1m - 50m)
Indexing:
: Integrated Alignment Key
Micro MATE-N-LOK 3.0mm 14-Pin to 0.110 Faston Multi-Branch Motor Luminaire Wire Harness | EDOM
INDUSTRIAL WIRE HARNESS

Micro MATE-N-LOK 3.0mm 14-Pin to 0.110 Faston Multi-Branch Motor Luminaire Wire Harness | EDOM

Alt. for: 1-794617-4 (Housing), TE 1-794610-2 (Gold Contacts), TE 140717-1 (0.110 Faston Receptacles) Mates With: 3.0mm 14-Pin Headers (e.g., 1-794618-4 / 1-794620-4) or standard 0.110" (2.8mm) Male Quick-Disconnect Tabs
Harness Type
: Micro MATE-N-LOK 3.0mm 14-Pin to 0.110 Faston Splitter Harness
Connector P1
: 14-Position Receptacle Housing, 3.0mm Pitch (TE 1-794617-4 equivalent)
Secondary Terminations (P2)
: 16x 0.110" (2.8mm) Non-Insulated Quick-Connect Receptacles (TE 140717-1 equivalent)
Wire Gauge & Style
: UL1007 22 AWG Stranded Wire (Red / Blue)
Branch Lengths
: Signal Leads: 500±10 mm to 600±10 mm; Daisy-Chain Links: 150±10 mm
Identification & Marking
: Digital White Heat Shrink Tubing with Printed Wire Markers (KP1–KP8, +12V)
Terminal Pull Force Standard
: UL486A Compliance
Manufacturing Standard
: IPC/WHMA-A-620E Compliance
Packaging Method
: 10 PCS / PE Bag + Label
Environmental Compliance
: RoHS Compliant
Micro MATE-N-LOK 3.0mm 2-Pin to 2-Pin RGB Luminaire Wire Harness 300mm | EDOM
INDUSTRIAL WIRE HARNESS

Micro MATE-N-LOK 3.0mm 2-Pin to 2-Pin RGB Luminaire Wire Harness 300mm | EDOM

Intermateable With: 1445022-2 / TE Connectivity 1-794606-1 Mates With: 3.0mm Pitch Headers (e.g., TE 1445055-2, 1445053-2) & Micro-Fit 3.0 43045 Series Pin Headers
Harness Type
: Point-to-Point Luminaire Power / RGB Wire Harness
Connector A
: 2-Position Micro MATE-N-LOK 3.0mm Receptacle Housing
Connector B
: 2-Position Micro MATE-N-LOK 3.0mm Receptacle Housing
Number of Positions
: 2 Pins (Single Row, 3.00 mm Centerline Pitch)
Wire Gauge & Style
: 24 AWG Stranded Copper (UL AWM 1007, Red & Blue)
Overall Assembly Length
: 300 mm ± 5 mm
Packaging Method & Quantity
: 10 PCS / PE Bag with Label
Manufacturing Standard
: IPC/WHMA-A-620E Standard & UL 486A Pull Force Reference
Standard Compliance
: RoHS, REACH Compliant
Micro MATE-N-LOK 3.0mm 2-Pin to Pigtail Heater Wire Harness 200mm | EDOM
INDUSTRIAL WIRE HARNESS

Micro MATE-N-LOK 3.0mm 2-Pin to Pigtail Heater Wire Harness 200mm | EDOM

Intermateable With: 1445022-2 / TE Connectivity 1-794610-2 Mates With: 3.0mm Pitch Headers (e.g., TE 1445055-2, 1445053-2) & Molex Micro-Fit 3.0 43045 Series Pin Headers
Harness Type
: Single-Ended Heater Power / Control Pigtail Wire Harness
Connector A
: 2-Position Micro MATE-N-LOK 3.0mm Receptacle Housing
Connector B
: Blunt Cut / Stripped Pigtail Wire Leads (P2)
Number of Positions
: 2 Pins (Single Row, 3.00 mm Centerline Pitch)
Wire Gauge & Style
: 24 AWG Stranded Copper (UL AWM 1007, Red & Blue)
Overall Assembly Length
: 200 mm ± 5 mm
Packaging Method & Quantity
: 10 PCS / PE Bag with Label
Manufacturing Standard
: IPC/WHMA-A-620E Standard & UL 486A Pull Force Reference
Standard Compliance
: RoHS, REACH Compliant
Micro MATE-N-LOK 3.0mm Pitch Wire Harness 8-Pin to 4-Pin & 2-Pin Splitter Cable | EDOM
INDUSTRIAL WIRE HARNESS

Micro MATE-N-LOK 3.0mm Pitch Wire Harness 8-Pin to 4-Pin & 2-Pin Splitter Cable | EDOM

Alt. for: (794617-8 / 794617-4 / 1445022-2 harness assemblies) Mates With: 3.0mm Headers (794618 / 794620 Series) or Molex 43045 Micro-Fit 3.0 Headers
Harness Type
: Micro MATE-N-LOK 3.0mm Splitter Cable Assembly
Connector P1
: 8-Position Receptacle Housing, 3.0mm Pitch (TE 794617-8 equivalent)
Connector P2
: 4-Position Receptacle Housing, 3.0mm Pitch (TE 794617-4 equivalent)
Connector P3
: 2-Position Receptacle Housing, 3.0mm Pitch (TE 1445022-2 equivalent)
Wire Gauge & Style
: UL1007 24 AWG Stranded Wire (Red / Blue)
Overall Branch Lengths
: Branch 1: 560±10 mm / Branch 2: 500±10 mm
Crimp Standard
: UL486A Terminal Pulling Force Compliance
Manufacturing Standard
: IPC/WHMA-A-620E Compliance
Packaging Method
: 10 PCS / PE Bag + Label
Environmental Compliance
: RoHS Compliant
MIL-DTL-26482 26-Pin Circular to Samtec Mini-Mate & Delphi Pressure Transducer Wire Harness | EDOM
INDUSTRIAL WIRE HARNESS

MIL-DTL-26482 26-Pin Circular to Samtec Mini-Mate & Delphi Pressure Transducer Wire Harness | EDOM

Drop-in for: MS3122E16-26S / Samtec IPD1 Series / Delphi 12110192 Mates With: MIL-DTL-26482 Shell Size 16 26-Pin Male Plugs, Samtec IPL1 Series Headers, and Metri-Pack 150 Series Shrouds
Harness / Cable Type
: Multi-Branch DIGOUT / Analog / Speed Sensor Wire Harness
Main Interface (End A)
: 26-Pin Circular Receptacle (ITT Cannon MS3122E16-26S, Size 20 Contacts)
Secondary Interfaces (End B)
: Samtec IPD1-02-D-K (4P), IPD1-04-D-K (8P), IPD1-12-D-K (24P x 2)
Sensor Interfaces
: 2x Delphi 12110192 3-Pin Sealed Pressure Transducer Connectors
Wire Gauge & Conductor Length
: 20 AWG Discrete Stranded Wire (532 Inches Total Wire Length)
Branch Cut Lengths
: 9.5", 12.0", 14.0", 15.0", 27.0" (Centerline extended measurement)
Cavity Population
: Female Crimp Contacts Pre-Loaded in Unused Samtec Positions
Identification & Labeling
: 42x Heat-Shrink Wire Markers + Self-Laminating Cable Label
Workmanship Standard
: IPC/WHMA-A-620 Class 2
MIL-DTL-26482 41-Pin Circular to Samtec Mini-Mate Industrial DIGIN Power Wire Harness | EDOM
INDUSTRIAL WIRE HARNESS

MIL-DTL-26482 41-Pin Circular to Samtec Mini-Mate Industrial DIGIN Power Wire Harness | EDOM

Drop-in for: MS3122E20-41S / Samtec IPD1 Series Mates With: MIL-DTL-26482 Shell Size 20 41-Pin Male Plugs & Samtec IPL1 / MMSD 2.54mm Pitch Headers
Harness / Cable Type
: Multi-Branch Industrial DIGIN / Power Wire Harness
End A Main Connector
: ITT Cannon MS3122E20-41S (41-Pin Circular Receptacle, Shell Size 20)
End B Branch Connectors
: Samtec IPD1-02-D-K (4-Pin), IPD1-12-D-K (24-Pin), IPD1-20-D-K (40-Pin)
Auxiliary Terminations
: 1/4" Fast-On Spade Receptacles (AMP 640903-1 x 5, AMP 640905-1 x 3)
Conductor Wire Gauge
: 20 AWG Stranded Discrete Wire (622.5 Inches Total Wire Length)
Harness Branch Lengths
: 7.0", 9.0", 11.0", 13.0", 14.0" (Measured along extended centerline)
Unused Cavity Loading
: Pre-loaded with Size 20 Contacts & MS27488-20 Sealing Plugs
Identification Markers
: 55 Heat-Shrink Wire Markers + Self-Laminating Cable Label
Manufacturing Standard
: IPC/WHMA-A-620 Class 2
