What is a standard M12 circular connector?
You’ve probably searched “standard M12 connector” expecting a simple answer. But if you’ve ever received the wrong cable...
Detailed Product Information
Technical Data & Reference
Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.
Competitor & Cross-Reference
- Alternative Type
- Intermateable With
- Competitor Part Number
- Phoenix Contact SACC-E-M12MS-3/4/5/6CON Series, Binder 713/763 Series (C-Coded Male Receptacles), TE Connectivity M12 C-Code Panel Mount Series
- Mates With
- Standard M12x1 C-Coded Female Sockets, Field-Wireable Plugs, or Overmolded Female Cable Assemblies conforming to IEC 61076-2-101
Intermateable: This part is mechanically and electrically compatible for mating with the listed competitor connector. Mixed use in the same connector system is supported.
Technical Specifications
- Connector Type
- M12 Male Device Connector Plug (Panel Receptacle)
- Coding & Number of Pins
- C-Code (3 Pin, 4 Pin, 5 Pin, 6 Pin)
- Mounting Type
- Rear Panel Mount, Straight Through-Hole (DIP PCB Solder Pins)
- Mating & Panel Threads
- Mating Thread: M12x1; Panel Mounting Thread: PG9 or M16x1.5
- Key Dimensions
- Body Length: 19.8mm; Pin Extension Length: 13.40mm
- Recommended Panel Cutout & Thickness
- PG9: Ø15.3 (+0.1/-0) mm; M16: Ø16.1 (+0.1/-0) mm; Anti-Rotation Flat: 13.5 (+0.1/-0) mm; Max Panel Thickness: 3.0mm
- Mating Durability
- ≥ 500 Mating Cycles
- Ingress Protection
- IP67 (in correct locking state)
- Standard Compliance
- IEC 61076-2-101, RoHS Compliant
Material Composition
| Material | Value / Description |
|---|---|
| Insulation Housing | Polyamide (PA), Black |
| Contact Material & Plating | Copper Alloy, Gold Plated |
| Metal Shell | Copper Alloy, Nickel Plated |
| Metal Locking Nut | Copper Alloy, Nickel Plated |
| Sealing O-Ring | Silicone Rubber, Black |
| Potting Compound | Epoxy Resin, Black |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Rated Current | 4A (C-Code 3 Pin, 4 Pin); 2A (C-Code 5 Pin, 6 Pin) |
| Rated Voltage | 250V DC (3 Pin, 4 Pin); 60V DC (5 Pin); 30V DC (6 Pin) |
| Operating Temperature Range | -40°C to +80°C |
| General Tolerances | Linear dimensions: ±0.15mm to ±0.50mm |
Application Scenarios
-
AC Sensor & Limit Switch Connectivity: C-Code dual-keyway design provides dedicated polarization for AC proximity sensors and safety switches.
-
Industrial Actuators & Motor Control: Transmits up to 250V/4A to pneumatic valves, solenoid switches, and auxiliary drive units.
-
Programmable Logic Controller (PLC) Cabinets: Serves as a rugged panel bulkhead interface connecting external sensors to internal I/O boards.
-
Heavy Machinery & Factory Automation Enclosures: IP67 silicone-sealed housing ensures reliable board-level power and signal pass-through under oil and dust exposure.
Frequently Asked Questions
What are the enclosure panel cutout specifications and maximum thickness for this M12 C-code male plug?
This M12 C-code male connector requires a D-shaped panel cutout with an anti-rotation flat width of 13.5mm (+0.1/-0mm). The borehole diameter is Ø15.3mm (+0.1/-0mm) for the PG9 thread variant and Ø16.1mm (+0.1/-0mm) for the M16x1.5 thread variant, supporting a maximum enclosure panel thickness of 3.0mm.
What is the primary difference between M12 A-Code and C-Code connectors in industrial equipment?
M12 C-Code connectors utilize a dual keyway polarization specifically engineered for AC sensor, actuator, and power-switching circuits, preventing accidental cross-mating with standard single-keyway A-Code DC sensors or D-Code Ethernet devices.
What electrical ratings and pin counts are supported by this M12 C-code PCB plug?
According to Table 1, the 3-pin and 4-pin C-code configurations deliver up to 4A at 250V DC, whereas the 5-pin configuration supports 2A at 60V DC and the 6-pin configuration provides 2A at 30V DC, all compliant with IEC 61076-2-101.
How does the rear mount design achieve IP67 environmental sealing?
The receptacle achieves IP67 ingress protection through a black silicone O-ring seated against the exterior panel wall combined with complete black epoxy resin potting encapsulating the rear PCB solder pins, operating reliably across a temperature range of -40°C to +80°C.
Overview and Application Notes
The M12 C-Code Male Rear Panel Mount Device Connector Plug is engineered with straight through-hole DIP PCB solder pins for industrial AC actuator controls, dual-keyway sensors, and field device bulkhead interfaces. Designed in compliance with IEC 61076-2-101 standards, this connector series offers 3-pin, 4-pin, 5-pin, and 6-pin configurations with PG9 or M16x1.5 panel mounting threads. Featuring an overall body length of 19.8mm, high-grade nickel-plated copper alloy housing, and rear black epoxy potting, it ensures dependable IP67 waterproof ingress protection in harsh industrial automation environments.
Key Features
- Standardized M12 C-Coding: Features dual keyway polarization (C-Code) across 3-Pin, 4-Pin, 5-Pin, and 6-Pin options to prevent mismating in AC sensor and power-switching circuits.
- Dual Thread & Panel Integration: Available in PG9 and M16x1.5 mounting threads with an integrated anti-rotation D-flat profile and a maximum panel thickness allowance of 3.0mm.
- Industrial-Grade Electrical Performance: Delivers rated currents up to 4A (3/4-pin at 250V DC) and 2A (5-pin at 60V DC / 6-pin at 30V DC) for reliable signal and power feeding.
- Rugged Environmental Sealing: Constructed with black polyamide (PA) insulation, gold-plated copper alloy male pins, and a silicone O-ring with black epoxy potting, delivering IP67 sealing and ≥500 mating cycles over -40°C to +80°C.
Engineering Specifications & PCB Integration
Engineered for rear panel bulkhead installation, this M12 male receptacle requires a D-shaped anti-rotation panel cutout with a flat dimension of 13.5mm (+0.1/-0mm) and a bore diameter of Ø15.3mm (+0.1/-0mm) for PG9 or Ø16.1mm (+0.1/-0mm) for M16x1.5 threads. The maximum enclosure panel thickness is 3.0mm. The straight PCB solder pins extend 13.40mm from the panel seating datum, facilitating direct through-hole solder termination into rigid board assemblies with optimal mechanical retention and grounding integrity.
