Standard HDMI Socket Pre-Molded Cable Assembly

Factory-backed connector sourcing and electric connection support for OEMs, distributors and electronic equipment manufacturers.

e-hdmi-cable
Product View
Standard HDMI Socket Pre-Molded Cable Assembly

OEM Ready

Factory Supply

Fast Quote

OEM & Manufacturing Advantages

Partner with us for factory-direct pricing, custom engineering, and complete compliance ready for global markets.

Custom Engineering Support

Tailored cable assembly & wire harness designs to meet your exact application requirements.

Full Technical Datasheets

Electrical ratings, mechanical drawings, material specs and compliance certifications on request.

Factory Direct Pricing

Competitive OEM & distributor pricing with flexible MOQ for both prototype and volume orders.

UL / CE Compliance Ready

Products engineered and tested to meet North American and European regulatory standards.

Need detailed parameters for this product?

Submit a quote request below -- our engineering team typically responds within one business day with full specifications, samples availability and lead times.

Detailed Product Information

Technical Data & Reference

Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.

Competitor & Cross-Reference

Mates With
Standard HDMI Type-A Plugs

Technical Specifications

Number of Pins
19 Pins
Key Position
HDMI Type A
Left Connector
HDMI Type A Plug
Right Connector
HDMI Type A Socket
AWG Gauge
24 AWG ~ 30 AWG (Customizable)
Connection Type
Plug and Unplug
Cable Length
Custom Lengths Available

Material Composition

Material Value / Description
Housing & Insulation LCP, Black
Contacts Copper Alloy, Gold-Plated
Shell Copper Alloy, Gold-Plated
Shielding Braided Shield
Overmolding PVC
Conductor Tinned Copper
Jacket PVC / TPE

Technical Characteristics

Characteristic Value
Rated Voltage / Current 30V AC / 1A per Pin
Operating Temperature -25°C ~ +85°C
Contact Resistance ≤ 10 mΩ
Insulation Resistance ≥ 100 MΩ
Durability ≥ 10,000 Mating Cycles
Flame Retardant Grade VW-1 / UL94V-0
Production Standards IPC/WHMA-A-620

Application Scenarios

  • Industrial Control & Automation Vision Systems: Provides reliable, high-speed video signal transmission between machine vision cameras and industrial display monitors.

  • Commercial Digital Signage & Kiosks: Delivers stable 4K/8K display connectivity inside space-constrained commercial public terminals and advertising displays.

  • Medical Diagnostic Imaging Carts: Ensures robust and secure video feed connections for mobile medical display units and diagnostic equipment.

  • Professional AV & Broadcasting Equipment: Facilitates clean internal signal extension and external interface management in high-density media production racks.

Frequently Asked Questions

Can you customize the length and wire gauge for this HDMI socket cable assembly?
Yes. As an OEM manufacturer, we offer fully tailored cable lengths and wire gauges (ranging from 24 to 30 AWG) to match your specific signal attenuation and spatial requirements.
Does this assembly support 4K and 8K high-definition video standards?
Yes, our cables are engineered to support HDMI 2.0 (4K@60Hz) and HDMI 2.1 (8K@60Hz) specifications, depending on the selected wire gauge and total cable length.
What manufacturing and quality standards do you follow?
All cable assemblies are produced strictly according to IPC/WHMA-A-620 guidelines, utilizing UL94V-0 and VW-1 flame-retardant materials for guaranteed safety and durability.
What is the typical Minimum Order Quantity (MOQ) for custom orders?
While we accommodate low-MOQ engineering sample runs for initial validation, our standard production MOQ typically ranges from 500 to 1,000 pieces per specification.
What is the standard lead time for bulk delivery?
Typical production lead time is 2 to 4 weeks following drawing sign-off and sample confirmation. Expedited options may be available depending on raw material stock.

Overview and Application Notes

Overview: Our Standard HDMI Socket Pre-Molded Cable Assembly is designed to provide secure, high-speed audio and video connectivity for industrial and commercial display systems. Featuring a standard HDMI Type-A socket termination, this pre-molded assembly ensures robust strain relief and reliable signal integrity for 4K and 8K applications. As a direct OEM manufacturer, we offer full customization of cable lengths, wire gauges (24-30 AWG), and jacket materials, all manufactured to rigorous IPC/WHMA-A-620 standards.

Application Notes:

  • Ensure proper strain relief at the socket end when routing cables through tight equipment enclosures to prevent conductor fatigue.

  • Verify adequate bend radius compliance during installation to protect internal tinned copper shielding from micro-deformation.

  • Check that mating HDMI Type-A plugs are fully inserted and aligned to avoid misalignment stress on the 19-pin contact array.

  • For high-EMI industrial environments, ensure proper grounding of the cable shield to minimize signal attenuation or packet loss.
