Detailed Product Information
Technical Data & Reference
Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.
Specifications
- Number of Pins
- 9 Pins
- Key Position
- Type A
- Left Connector
- USB3.0 Plug
- Right Connector
- USB3.0 Socket
- AWG Gauge
- 22 AWG ~ 30 AWG
- Connection Type
- Plug and unplug
- Wires & Cables Length
- Customization length
Material Composition
| Material | Value / Description |
|---|---|
| Housing & Insulation | PA, Whtie |
| Contacts | Copper Alloy, Tin & Gold-Plated |
| Shell | Copper Alloy, Nickel & Gold-Plated |
| Sealing | - |
| Shielding | Shield |
| Overmolding | PVC |
| Wires & Cables Conductor | Tinned Copper |
| Wires & Cables Jacket | PVC / TPE |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Rated Current | 2A |
| Rated Voltage | 30V |
| Rated Temperature | -25°C ~ + 85°C |
| Flame Retardant Grade | VW-1 / UL94V-0 |
| Insulation Resistance | ≥ 100 MΩ |
| Contact Resistance | ≤10mΩ |
| Durability | ≥ 1000 Times |
| Protection Grade | - |
| Product Certification | RoHS Compliant, UL94V-0 Material |
| Production Design Standards | IPC 620 |
Application Scenarios
-
Machine Vision Systems: Delivers stable, high-bandwidth connections between industrial cameras and image processing units for real-time quality inspection.
-
Industrial Automation: Ideal for extending data ports on PLCs, industrial PCs (IPCs), and robotic control cabinets in smart manufacturing facilities.
-
Testing & Diagnostic Equipment: Provides reliable plug-and-play interfaces for laboratory instruments and medical testing devices.
-
Self-Service Terminals: Ensures durable internal routing for ATMs, kiosks, and vending machines requiring high-speed data peripheral connectivity.
Frequently Asked Questions
Can I customize the length and wire gauge of this USB 3.0 cable assembly?
Yes. We offer full OEM customization. You can specify the exact cable length and choose AWG gauges ranging from 22 AWG to 30 AWG based on your power (up to 2A/30V) and data routing needs.
Are these cables shielded against EMI for industrial use?
Absolutely. Our standard USB 3.0 cable assemblies feature comprehensive shielding to protect high-speed data signals from electromagnetic interference (EMI) commonly found in factory and automation environments.
What manufacturing standards do your cable assemblies meet?
Our production strictly follows IPC 620 standards for cable and wire harness assemblies, and the materials meet VW-1 / UL94V-0 flame retardant specifications.
How can I get a sample for prototype testing?
You can easily request a sample by clicking "Request a Quote." Our engineering team will review your specific requirements and arrange prototype samples with flexible MOQs.
Overview and Application Notes
Product Overview: Industrial-Grade USB 3.0 Cable Assembly
Engineered for high-speed data transfer and robust power delivery, this Standard 9-Pin USB 3.0 Plug-to-Socket Cable Assembly is a vital interconnect solution for industrial automation, vision systems, and commercial OEM equipment.
Designed to seamlessly extend USB 3.0 connections while maintaining optimal signal integrity, it features heavy-duty shielding and premium PVC/TPE overmolding to withstand the harsh conditions of factory floors and continuous-use environments.
Core Technical Advantages
-
High-Speed & Stable Transmission: Fully shielded tinned copper conductors (available in 22 AWG to 30 AWG) prevent electromagnetic interference (EMI), ensuring zero-latency data transmission for critical machine vision applications.
-
Industrial Durability: Featuring gold-plated copper alloy contacts and rated for over 1,000 mating cycles, this cable is built for longevity. It operates safely within a broad temperature range of -25°C to +85°C.
-
Certified Manufacturing Standards: Produced in strict accordance with IPC 620 production design standards and featuring VW-1 / UL94V-0 flame-retardant grades, guaranteeing safety and compliance for global equipment deployment.
OEM Customization & Support
As a direct-to-factory manufacturer, EDOM Electronics offers flexible OEM/ODM services. We can customize cable lengths, wire gauges, and jacket materials to precisely match your equipment’s mechanical and electrical requirements.
