Detailed Product Information
Technical Data & Reference
Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.
Competitor & Cross-Reference
- Alternative Type
- Drop-in Replacement
- Competitor Part Number
- Wurth Elektronik 692112030100 / Amphenol GSB31 Series (Vertical H15.0mm configurations)
- Mates With
- Standard USB 3.0 & 2.0 Type-A Male Cable Assemblies
Drop-in Replacement: This part is a direct, pin-compatible substitute for the competitor part number listed above. No design modification required.
Material Composition
| Material | Value / Description |
|---|---|
| Housing Material | PBT, Blue (UL 94V-0) |
| Contact Material | Copper Alloy |
| Contact Plating | Gold Flash on Contact Area, Tin on Solder Tails |
| Shielding Shell | Copper Alloy, Nickel Plated |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Data Transfer Rate | Up to 5 Gbps (SuperSpeed) |
| Rated Voltage | 30V AC (RMS) Max |
| Rated Current | 1.5A |
| Contact Resistance | 30 mΩ Max (Initial) |
| Insulation Resistance | 1000 MΩ Min |
| Dielectric Withstanding | 500V AC for 1 minute |
| Operating Temperature | -55°C to +105°C |
Application Scenarios
-
Industrial PCs (IPCs) & Embedded Motherboards: Provides a space-saving, vertically oriented high-speed data interface where standard horizontal edge mounting is not feasible due to enclosure constraints.
-
Networking & Edge Routers: Acts as a reliable physical diagnostic, firmware update, or memory expansion interface on the top face of telecommunications boards across -55°C to +105°C.
-
Medical & Diagnostic Carts: Guarantees secure, high-bandwidth data logging for stationary medical equipment requiring frequent peripheral connections.
-
Smart Kiosks & POS Terminals: Delivers long-term reliability and easy vertical access for maintenance technicians in high-traffic retail and self-service environments.
Frequently Asked Questions
Is this vertical USB connector manufactured in-house, or are you a distributor?
We are an ISO-certified direct manufacturer. We handle the entire engineering, tooling, and OEM/ODM mass production process in-house, ensuring factory-direct pricing and strict quality control.
What are the electrical ratings and operating temperature for this 15.0mm elevated receptacle?
This receptacle supports a rated current of 1.5A, contact resistance of 30 mΩ max, insulation resistance of 1000 MΩ min, dielectric withstanding voltage of 500V AC (1 min), and an extended operating temperature range of -55°C to +105°C.
What materials are used in the construction of this connector?
The insulator is molded from blue PBT (UL 94V-0 rated), contacts are copper alloy with gold plating on mating areas and tin on solder tails, and the shielding shell is made of nickel-plated copper alloy featuring integrated reinforcing ribs.
What is the standard lead time and MOQ for mass production?
Our standard mass production lead time is typically 2 to 3 weeks. Prototyping takes only 3 to 5 days. We offer flexible MOQs to support both prototyping phases and high-volume continuous manufacturing.
Overview and Application Notes
Overview Engineered for reliable high-speed 5 Gbps data transmission in industrial and commercial electronics, this vertical USB 3.0 Type-A receptacle provides an elevated top-mount connectivity solution for deep chassis designs. Featuring a 180-degree vertical through-hole (DIP) orientation with an elevated 15.0mm height profile, it bridges the clearance gap between the PCB surface and thick external enclosure panels. The copper alloy shell stakes feature integrated reinforcing ribs to ensure superior mechanical retention and resist heavy insertion force. Molded from blue PBT thermoplastic (UL 94V-0) and rated for an extended operating temperature range of -55°C to +105°C, this connector delivers consistent electrical stability with a 1.5A contact current rating. As an ISO-certified direct manufacturer, EDOM Electronics provides factory pricing, scalable production, and customized contact plating options to meet your exact engineering requirements.
Application Notes
-
Mechanical Grounding & Reinforcing Ribs: The outer nickel-plated copper alloy shell features integrated reinforcing ribs and through-hole board stakes. These must be wave-soldered securely to the PCB ground plane to dissipate insertion stress and ensure continuous 360° EMI/RFI shielding.
-
Z-Axis Clearance & Enclosure Alignment: This connector features an elevated 15.0mm height profile. Ensure your chassis cutout and mating cable overmold account for this vertical elevation during the mechanical layout phase.
-
PCB Footprint Tolerances: Strictly follow the recommended PCB layout (9-φ0.70mm signal pin holes, 2-φ2.30mm shell retention holes) to prevent terminal bending and stress during manual or automated DIP insertion.
-
Thermal Compatibility: Molded from blue PBT (UL 94V-0), the housing is fully compatible with standard wave soldering processes within an operating temperature range of -55°C to +105°C.
-
Impedance Control: Maintain 90Ω differential trace impedance on the motherboard for the SuperSpeed (TX/RX) differential pairs to prevent signal loss at 5 Gbps data rates.
