Detailed Product Information
Technical Data & Reference
Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.
Competitor & Cross-Reference
- Alternative Type
- Drop-in Replacement
- Competitor Part Number
- Molex 46765-0301 / 46765-1001 (Micro HDMI Type D Series)
- Mates With
- Standard Micro HDMI Type D Male Plug / Cable Assemblies
Drop-in Replacement: This part is a direct, pin-compatible substitute for the competitor part number listed above. No design modification required.
Technical Specifications
- Connector Type
- Micro HDMI (Type D) Receptacle / Female
- Number of Positions / Pins
- 19 Pins
- Mounting Type
- Straddle Mount / Edge Mount
- Key Dimensions
- 12.70 mm (L) × 8.30 mm (W) × 3.80 mm (H)
- Mating Interface Length
- 7.00 ± 0.05 mm
- Contact Pitch
- 0.75 mm (Contact Width: 6.75 mm)
- Compatible PCB Thickness
- 1.00 mm / 1.20 mm
- Mechanical Mating Durability
- 5,000 Cycles (at 100 ± 50 cycles/hr)
- Insertion / Withdrawal Force
- Insertion: 4.5 kgf Max. / Removal: 0.5 kgf Min., 2.5 kgf Max.
- Standard Compliance
- RoHS Compliant
Material Composition
| Material | Value / Description |
|---|---|
| Housing Material | LCP, UL 94V-0 Rated, Black |
| Insert Housing | LCP, UL 94V-0 Rated, Black |
| Contact Material (10P & 9P) | C5191 Phosphor Bronze |
| Contact Plating | Contact Area: Gold Plated over 50u" Ni min.; Solder Area: 100u" Mist Tin over 50u" Ni min. |
| Shell Material & Plating | C2680 Brass, Gold Flash (G/F) Plated over 50u" Ni min. |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Rated Voltage | 40V AC/DC Maximum |
| Rated Current | 0.3A Maximum |
| Dielectric Strength | 150V AC / 1 Minute |
| Insulation Resistance | 150V DC, 10 MΩ Minimum |
| Contact Resistance | 30 mΩ Maximum |
| Operating Temperature Range | -25°C to +85°C |
| General Tolerances | 3 Places: ±0.15 mm; 2 Places: ±0.25 mm; 1 Place: ±0.35 mm; Angular: ±3° |
Application Scenarios
-
Single-board computers (SBC) and compact industrial edge gateways
-
Drone HD FPV video transmission modules and gimbal camera outputs
-
Ultra-thin portable test instruments and handheld medical displays
-
Commercial digital signage micro-media players
-
Automotive in-cabin smart mirror and secondary display feeds
Frequently Asked Questions
What PCB edge thickness is supported by this Micro HDMI Type D connector?
The connector features a dual-specification straddle slot: Option 1 accommodates 1.20 mm PCB thickness with slot dimensions of 1.10 mm (DIM A) / 1.15 mm (DIM B), while Option 2 supports 1.00 mm PCB thickness with slot dimensions of 0.90 mm (DIM A) / 0.95 mm (DIM B).
What are the plating and soldering specifications for the contact pins?
The C5191 phosphor bronze contacts are electroplated with selective gold over 50u" nickel minimum on the contact area for corrosion resistance and stable signal transfer, paired with 100u" mist tin over 50u" nickel minimum on the straddle lead tails to guarantee high wetting and joint reliability during reflow.
What electrical and durability ratings does this receptacle satisfy?
It is rated at 40V AC/DC and 0.3A max, with a dielectric withstanding capability of 150V AC for 1 minute and a maximum contact resistance of 30 mΩ. The assembly sustains up to 5,000 mating cycles under standard mechanical testing conditions (insertion force ≤ 4.5 kgf; extraction force 0.5–2.5 kgf).
Overview and Application Notes
The Micro HDMI Type D Female 19-Pin connector is engineered for edge-straddle (edge-mount) PCB termination, accommodating printed circuit board thicknesses from 1.00 mm to 1.20 mm. Featuring a compact 8.30 mm interface width, high-grade LCP UL 94V-0 dielectric housing, and multi-layer selective gold/tin plating, it delivers high-integrity digital audio/video transmission in ultra-slim embedded hardware and compact industrial electronics.
Key Features
- Standard 19-Pin Type D Configuration: Fully compliant with HDMI 1.4/2.0 physical transmission standards for compact audio/video interfaces.
- Versatile Straddle Mounting: Dual-flange design supports both 1.00 mm and 1.20 mm edge-mount PCB designs.
- Robust Shielding & Durability: C2680 alloy shell with Nickel over-plating provides reliable EMI shielding across 5,000 mating cycles.
- High-Conductivity Terminals: C5191 phosphor bronze contacts with selective gold plating in the contact zone and mist tin in the solder zone.
- Industrial Temperature Range: Certified for continuous operation from -25°C to +85°C.
Engineering Specifications & PCB Integration
This connector employs a straddle-mount edge configuration with a rear slot clearance of 0.90 mm–1.10 mm (DIM A) to 0.95 mm–1.15 mm (DIM B), enabling rigid solder clamping onto 1.00 mm or 1.20 mm nominal edge boards. The contact tail pitch is 0.75 mm across a 6.75 mm contact span, requiring precise solder pad alignment to prevent bridging. Maintain PCB edge chamfer within 0.15 mm to facilitate smooth slot seating prior to reflow or manual soldering.
