Detailed Product Information
Technical Data & Reference
Structured parameters, material notes, application context and frequently asked questions for engineering and procurement evaluation.
Competitor & Cross-Reference
- Alternative Type
- Drop-in Replacement
- Competitor Part Number
- Binder Series 707 (e.g., M5 4-Pin Female Cable equivalents), TE Connectivity M5 Series.
- Mates With
- Standard M5 4-pin panel mount receptacles or male plugs (e.g., Binder 707 Series Male Plugs).
Drop-in Replacement: This part is a direct, pin-compatible substitute for the competitor part number listed above. No design modification required.
Technical Specifications
- Number of Pins
- 4 Pins
- Key Position
- Standard M5
- Left Connector
- M5 Female Socket (Overmolded)
- Right Connector
- Custom (Bare wire, Male Plug, etc.)
- AWG Gauge
- 26 AWG (Standard for M5)
- Connection Type
- Threaded Screw Locking (M5x0.5)
- IP Rating
- IP67 (Mated Condition)
- Cable Length
- Fully Customizable
Material Composition
| Material | Value / Description |
|---|---|
| Housing & Insulation | PA (Polyamide), UL94 V-0 |
| Contacts | Copper Alloy, Gold-Plated |
| Shell / Nut | Brass, Nickel-Plated |
| Sealing | NBR / FKM O-Ring |
| Shielding | Optional (Tinned Copper Braid) |
| Overmolding | PVC or TPU |
| Wire Conductor | Stranded Tinned Copper |
| Cable Jacket | Industrial PVC / TPU |
Technical Characteristics
| Characteristic | Value |
|---|---|
| Current Rating | 1A per contact |
| Voltage Rating | 60V AC / DC |
| Contact Resistance | ≤ 3 mΩ |
| Insulation Resistance | ≥ 100 MΩ |
| Operating Temp. | -25°C to +80°C |
| Mating Cycles | ≥ 500 Cycles |
Application Scenarios
-
Miniature Industrial Sensors: Provides secure, IP67-rated connectivity for tiny proximity, inductive, and photoelectric sensors where standard M8 or M12 connectors are simply too large.
-
Robotics & Micro-Automation: Delivers highly flexible and lightweight signal transmission for robotic arms, end-of-arm tooling, and micro-actuators requiring reliable continuous operation in tight spaces.
-
Machine Vision & Optics: Ensures stable power delivery and signal triggering for compact inspection cameras and laser scanners on high-speed factory production lines.
-
Medical & Diagnostic Equipment: Offers discrete, safe, and easily routable connections for portable diagnostic devices and laboratory automation instruments requiring space-saving, moisture-resistant designs.
-
Commercial Drones (UAVs): Acts as an ultra-compact, lightweight interconnect solution for transferring critical sensor data within the confined payloads of unmanned aerial vehicles.
Frequently Asked Questions
What is the main advantage of an M5 connector over an M8?
The M5 connector is significantly smaller in diameter (utilizing an M5x0.5 thread), making it the ideal choice for ultra-compact applications and miniature sensors where mounting space is severely restricted and an M8 connector will not fit.
Can I request a custom TPU jacket instead of standard PVC?
Absolutely. While PVC is excellent for static industrial environments, we highly recommend and can provide TPU (Thermoplastic Polyurethane) jackets for applications requiring continuous flexing, drag chains, or enhanced resistance to oils and harsh chemicals.
What does the IP67 waterproof rating entail for this specific cable?
When correctly mated and locked with a corresponding M5 receptacle, the connection is fully protected against dust ingress and can withstand temporary immersion in water up to 1 meter for 30 minutes, ensuring reliable operation in washdown or outdoor environments.
Are these cable assemblies compliant with international safety standards?
Yes, as an experienced OEM manufacturer, our raw materials and manufacturing processes are engineered to meet UL, CE, and RoHS compliance, ensuring seamless global market entry for your equipment.
What is the Minimum Order Quantity (MOQ) and lead time for custom OEM orders?
We offer flexible MOQs tailored to support both your initial prototyping phase and large-scale mass production. Standard OEM production lead times typically range from 2 to 4 weeks depending on specific material requirements and order volume.
Overview and Application Notes
Overview: Engineered for ultra-compact and space-constrained industrial applications, our M5 4-Pin Female Sensor Cable Assembly delivers reliable power and signal transmission for miniature sensors, actuators, and automation equipment. Featuring a highly precise M5x0.5 threaded locking mechanism, this assembly guarantees a secure, vibration-resistant connection with an IP67 waterproof rating when mated. Built with premium tinned copper conductors (typically 26 AWG), gold-plated contacts, and durable overmolding, it ensures excellent signal integrity in harsh environments. As a factory-direct OEM/ODM manufacturer, we offer full customization of cable lengths, jacket materials (PVC or TPU), and wire configurations, all manufactured to UL/CE compliance standards to seamlessly integrate into your global equipment designs.
Application Notes:
-
Space Optimization: Designed for micro-routing; ensure adequate finger clearance is maintained in your machinery layout to safely operate the miniature M5x0.5 threaded locking nut.
-
Torque Specifications: Do not over-tighten the miniature M5 screw ring. Apply the manufacturer-recommended torque to maintain the IP67 NBR seal without damaging the delicate metal threads.
-
EMI/RFI Shielding: For sensitive analog sensor signals, request our shielded cable option and ensure the 360-degree shield is properly grounded at the control cabinet to prevent high-frequency noise interference.
-
Dynamic Routing: Adhere to a minimum bend radius of 5x the cable’s outer diameter (OD) for static installations, or specify a TPU jacket if the application involves continuous dynamic flexing.
