USB 3.1 Type-C Receptacle, Mid-Mount 1.0mm Dual SMT, Short Body (L=8.75mm) (PN: EU24FB3N11305)

Drop-in for: 105444 Series / TE Connectivity 2320115 Series (Depending on exact PCB cutout tolerances) Mates With: 3.1 Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 3A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Surface Mount
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.1 Type-C Receptacle, Mid-Mount CH0.75mm Hybrid SMT+DIP L9.21mm (PN: EU24F2B3N11339SR)

Drop-in for: 105444 Series / TE Connectivity 2320115 Series (Depending on specific PCB cutout tolerances) Mates With: 3.2 Gen2 Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Hybrid
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.1 Type-C Receptacle, Top Mount Dual SMT R/A (PN: EU24FB3N11253)

Drop-in for: 105450-0101 / TE Connectivity 2320115-1 (Standard Top Mount 24-Pin Receptacles) Mates With: Standard USB Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 5V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.2 Gen 2 Type-C 24-Pin Receptacle, Mid-Mount Sink 1.60mm SMT (PN: EU24FB3N11249X)

Drop-in for: 2129691-1 / Molex 105444 Series (Requires verification of specific PCB footprint dimensions) Mates With: 3.2 Gen2 / USB4 specifications

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.2 Gen2
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : 100W
Contact Pin Type: : Surface Mount
Shell Stake Type: : Surface Mount
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.2 Gen 2 Type-C Elevated Receptacle, CH3.40mm Hybrid DIP/SMT (PN: EU24F2B3N32352SR)

Drop-in for: 217175 Series / TE 2320115 Equivalent Mates With: Standard USB Type-C Cable Plugs

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : Yes
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 5V AC
USB Connector Style: : Type C
USB Version: : 3.2 Gen2
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : 100W
Contact Pin Type: : Hybrid
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.2 Gen 2 Type-C Receptacle, Mid-Mount SMT CH0.55mm (PN: EU24F2B3N11385SR)

Drop-in for: 105444 Series / TE Connectivity 2320115 Series (Depending on specific PCB cutout tolerances) Mates With: 3.2 Gen2 Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 3A
Number of Contacts: : 24
Voltage Rating: : 5V AC
USB Connector Style: : Type C
USB Version: : 3.2 Gen2
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Surface Mount
Mating Face Lead In: : N/A

View Details Datasheet

USB Connectors

USB 3.2 Gen2 Type-C Receptacle, Mid-Mount 1.60mm, Dual SMT (PN: EU24F2B3N11406SR)

Drop-in for: 105444 Series / TE Connectivity 2320115 Series (Depending on exact PCB cutout tolerances) Mates With: Standard USB Type-C Plugs & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 1.5A
Number of Contacts: : 24
Voltage Rating: : 100V AC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : N/A

View Details Datasheet

USB Connectors

USB Type-C 16-Pin Elevated Receptacle, 4.3mm (PN: EU16F2B3N11413SR)

Alt. for: 2320115 series / Molex 105450 series (Functional equivalents for 16-pin elevated designs) Mates With: 16-Pin or 24-Pin Plugs (e.g., Molex 105444 series)

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : Yes
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 16
Voltage Rating: : 20V DC
USB Connector Style: : Type C
USB Version: : 2.0
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Outer shell stake
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB Type-C 16-Pin Receptacle, Mid-Mount, Single Row SMT (PN: EU16FB1N1369)

Alt. for: 2388726 Series (Functional Equivalent) Mates With: (16-Pin or 24-Pin) & Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 16
Voltage Rating: : 5V AC
USB Connector Style: : Type C
USB Version: : 2.0
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Surface Mount
Mating Face Lead In: : Without

View Details Datasheet
