USB 3.0 Type-B Receptacle, Vertical Through-Hole (PN: EU09F2L1N1253)

Drop-in for: 692222030100 / TE Connectivity 1932258 Series Mates With: 3.0 Type-B Cable Plugs

Gender: : Receptacle (socket)
PCB Orientation: : Vertical
Locating Peg: : Without
Elevated: : Yes
Mating Cycles: : 1,500
Current Rating: : 1.8A
Number of Contacts: : 9
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type B
USB Version: : 3.0
Interface: : B
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Edge Mount
Power Rating: : N/A
Contact Pin Type: : Through Hole
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.1 Gen 2 Type-A Female Receptacle, Mid-Mount (PN: EU09F2L3N11368SR)

Drop-in for: 3.1 Gen 2 Type-A mid-mount equivalents Mates With: 3.0 / 3.1 Type-A Male Plugs and Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 2A
Number of Contacts: : 9
Voltage Rating: : 48V DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : 240W
Contact Pin Type: : Surface Mount
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.1 Gen 2 Type-A Receptacle, Edge Mount, CH3.4mm (PN: EU09FB3N12295)

Drop-in for: GSB31 Series / TE Connectivity 1932768-1 equivalents (Edge Mount/Sink Type configurations) Mates With: 3.1, 3.0 & 2.0 Type-A Male Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 1,500
Current Rating: : 1.8A
Number of Contacts: : 9
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type A
USB Version: : 3.0
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Edge Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Through Hole
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.1 Type E Front Panel Internal Header, Key A, 20-Pin (PN: EU20F2B3N11350SR)

Alt. for: G881 Series (Functional Equivalents) Mates With: 3.1 Type E Front Panel Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 1,500
Current Rating: : 1.5A
Number of Contacts: : 2x10
Voltage Rating: : 30V AC/DC
USB Connector Style: : Type E
USB Version: : 3.1
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : With

View Details Datasheet

USB Connectors

USB 3.1 Type-C 16-Pin Receptacle, Top Mount, SMT (PN: EU16F2B3N11377SR)

Drop-in for: 105450 / TE Connectivity 2320115 series Mates With: Standard USB Type-C Plugs / USB Type-C Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 16
Voltage Rating: : 20V DC
USB Connector Style: : Type C
USB Version: : 3.1
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : N/A
Contact Pin Type: : Surface Mount
Shell Stake Type: : Surface Mount
Mating Face Lead In: : N/A

View Details Datasheet

USB Connectors

USB 3.2 Gen 2 Type-C Receptacle, 24-Pin SMT Top Mount (PN: EU24FB3N1130)

Drop-in for: 213716 Series / TE Connectivity 2305018-1 Mates With: Standard USB Type-C Plugs and Cable Assemblies

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 20V DC
USB Connector Style: : Type C
USB Version: : 3.2 Gen2
Interface: : A
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : 100W
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.2 Gen 2 Type-C Receptacle, Elevated SMT (PN: EU24F2B3N32352SR)

Drop-in for: 217175 Series / TE 2320115 Equivalent Mates With: Standard USB Type-C Cable Plugs

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : Yes
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 48V DC
USB Connector Style: : Type C
USB Version: : 3.2 Gen2
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Top Mount
Power Rating: : 240W
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.2 Gen2 Type-C Female Receptacle, Mid-Mount (PN: EU24FB3N11216)

Drop-in for: 2129691-1 / Amphenol 12401598-XX (Functional equivalent for Type-C mid-mount) Mates With: Standard USB Type-C Plugs (Cable Assemblies)

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : With
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 48V DC
USB Connector Style: : Type C
USB Version: : 3.2 Gen2
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : 240W
Contact Pin Type: : Surface Mount
Shell Stake Type: : Inner shell stake
Mating Face Lead In: : Without

View Details Datasheet

USB Connectors

USB 3.2 Gen2 Type-C Receptacle, 24-Pin Mid-Mount SMT (PN: EU24FB3N11249X)

Drop-in for: 2129691-1 / Molex 105444 Series (Requires verification of specific PCB footprint dimensions) Mates With: 3.2 Gen2 / USB4 specifications

Gender: : Receptacle (socket)
PCB Orientation: : Horizontal
Locating Peg: : Without
Elevated: : No
Mating Cycles: : 10,000
Current Rating: : 5A
Number of Contacts: : 24
Voltage Rating: : 48V DC
USB Connector Style: : Type C
USB Version: : 3.2 Gen2
Interface: : C
Waterproof: : N/A
Approvals: : N/A
PCB Mount Position: : Mid Mount
Power Rating: : 240W
Contact Pin Type: : Surface Mount
Shell Stake Type: : Surface Mount
Mating Face Lead In: : Without

View Details Datasheet
